PSH-4 · 4-Level Puzzle Parking System
A four-tier semi-automated puzzle car park for commercial projects demanding high parking ratios. The Omron PLC manages platform sequencing across four levels with safety sensors confirming every position — quadrupling the capacity of the base footprint with fully independent vehicle access on demand.
Features
- 4-tier grid: quadruples parking capacity per footprint
- 100% independent access: retrieve any car at any time without shuffling neighbours
- Omron PLC with optimised 4-level shuffle algorithm
- Safety sensors at all platform positions and entry gates
- Motor + steel rope — oil-free, low-maintenance throughout
- Modular construction: scale from 8 to 80+ bays on the same platform
- Over height, over lenght, over width detection
- CE certified; preferred for commercial parking operators and mixed-use developments
Specifications
| Levels | 4 |
|---|---|
| Access | 100% Independent |
| Capacity | 4× base footprint |
| Drive System | Electric Motor + Steel Rope |
| Control System | Omron PLC |
| Position Sensors | Over length, over height, over width |
| Bay Expansion | Modular |
| Vehicle Retrieval Time | 90–120 seconds |
| Safety | Wire Rope Loose Detection |
| Control Voltage | 24V DC |
| Power Supply | 3-phase 380V AC |
| Certification | CE Marked |
