2TPS & 2TPD · 2-Level 2-Post Hydraulic Pit Parking Lift
The 2TPS (single-wide) and 2TPD (double-wide) are the most widely deployed underground parking lifts in the KETTP range — a hydraulic direct-drive system. The 2TPS stores 2 cars, the 2TPD stores 4 cars side by side. Both are CE certified with hot-dip galvanized pit structure. A clean, elegant, space-maximizing solution for residential driveways, urban apartments, private garages, and commercial facilities.
Features
- 2TPS: single-wide 2-car pit lift — 1 underground + 1 at grade, zero visible structure
- 2TPD: double-wide 4-car pit lift — 2 underground + 2 at grade, shared pit excavation
- Hydraulic direct drive: powerful, smooth and simple
- Platform flush with ground when lowered — indistinguishable from surrounding floor
- Optional Hot-dip galvanized pit structure + IP65 limit switches for corrosion protection
- CE certified to BS EN 14010 standard for underground parking equipment
- Pin-Gear Balance Mechanism to ensure safety
- 24V DC safe control voltage; handset and optional automatic gate/door integration
Specifications
| Models | 2TPS (single-wide) / 2TPD (double-wide) |
|---|---|
| Vehicles | 2TPS: 2 cars | 2TPD: 4 cars |
| Levels | 2 (1 underground + 1 at grade) |
| Drive System | Hydraulic Direct Drive |
| Motor Power | 7.5 kW |
| Rated Capacity | 2,500 kg per vehicle platform |
| Pit Depth | ~2,100 mm |
| Balance system | Pin-Gear 2TPS |
| Pit Finish | Optional hot-dip galvanized steel |
| Limit Switches | IP65 rated |
| Control Voltage | 24V DC |
| Certification | CE / BS EN 14010 |
Enquiries: info@parking.bg · +359 888 452 770
